Rievtech RI3000-2S0022G 1-phase 2.2 kW frequency converter
Egyfázisú motorhoz Yes |
|
|
Power supply: 230 VAC / 50 Hz Output voltage: 3F 230 V AC Frequency range: 0 - 500 Hz Power: 2.2 kW (10 A) Load capacity: 150% - 1 minute 180% - 3 minutes Digital inputs: FWD / REV 8 digital channels 35 selectable functions Analog input: 0 - 10 V voltage 4-20 mA current Digital output: 1 relay output 1 transistor output (20 KHz) Analog output: 0 - 10 V voltage 4-20 mA current pulse Protection class: IP20 Dimensions: 184 * 98 * 135 |
|
| Availability: | In stock |
